Ridley Christ-Fire 58cm

Frame:
Ridley X-Fire 58

Fork/Headset:
Ridley Oryx Pro Tapered Full Carbon Fork

Crankset/Bottom Bracket:
Shimano Ultegra 6800 175mm with Stages Power Meter/ Wheels Manufacturing Angular Contact External BB

Pedals:
Shimano XT M8000 Race Pedals

Drivetrain/Cog/Chainring/Chain:
Shimano Ultegra 6800 46T + 34T/ Ultegra 11-32/ Shimano CN-HG901

Derailleurs/Shifters:
Shimano Ultegra RD and FD/ Shimano ST-RS685

Handlebars/Stem:
PRO Vibe Sprint 440mm/Thomson Elite X4 130mm -10 Degrees

Saddle/Seatpost:
Bontrager Montrose Elite/ Thomson Elite Inline

Brakes:
Shimano BR-RS785

Front Wheel/Hub/Tire:
DT Swiss 545d 36h/ Shimano FH-RS505/ Vittoria Revolution 700x35

Rear Wheel/Hub/Tire:
DT Swiss 545d 36h/ Shimano RH-RS505/ Vittoria Revolution 700x35

Accessories:
K-Edge Aero Mount, King Cage Iris Cages, Porcelain Rocket Frame Bag

Bike History

Click a link below to see past stages of this bike.

  1. Initial
  2. Frame Bag, Road Bike
  3. Commuter Mode

Added by Ozren0. Last updated almost 3 years ago.

As of almost 3 years ago, Ozren0 has indicated that they no longer own this bike.

9 Comments

ghostridethewhip

ghostridethewhip says:

Awesome

Posted almost 3 years ago

MCHammer666

MCHammer666 says:

How are you liking your PR bag? I'm thinking about ordering the same model myself but haven't heard any feedback on them.

Posted almost 3 years ago

Ozren0

Ozren0 says:

It's amazing. By far the best accessory.

Posted almost 3 years ago

pgreenwald

pgreenwald says:

I managed to fit a 41 Surly Knard in the front and a 35 Conti CycloXKing in the back

Posted almost 4 years ago

pgreenwald

pgreenwald says:

I recently acquired a 2010 Ridley X-Fire. Do you know what the max tire clearance is for this frame/fork?

Posted about 4 years ago

Ozren0

Ozren0 says:

I haven't played around with tire size, but given that I've seen this bike sold with 700x33's, I can estimate what it could fit.

For the frame, I doubt you could go too much bigger, MAYBE a 700x35 at most, as for the front, 700x40 or so. The fork has a lot more clearance than the rear. It is a "race" bike and as UCI doesn't allow tires bigger than 700x33, there's no need for the bike to fit them.

Posted about 4 years ago

pgreenwald

pgreenwald says:

Thanks for your response! I've got a 33 Clement mxp in the rear at the moment. Might try to squeeze in 40 WTB nano or 41 Surly Knard in the front

Posted about 4 years ago

Ozren0

Ozren0 says:

Let me know what size you end up fitting.

Posted about 4 years ago

Ozren0

Ozren0 says:

Hey, so I put in a 700x38 Challenge Gravel Grinder in the rear, and it fit. I think that a slick 700x40 or MAYBE a slightly knobby 700x40 would fit. Any luck with the Nano or the Knard?

Posted almost 4 years ago
